Long ol wok bilong 'hydraulic winching', i no gat wanpela prodak we i wok gut moa long 'HORN-DRIVE winch'. Ol strongpela 'hydraulic motor' i larim wok i go longpela taim. Ol strongpela ain, tupela-stej Planetary Gear Tren i save givim gutpela na gutpela wok na tu spit bilong lain. Olsem ol lektrik kasen bilong ol, ol dispela prodak i bihainim ol kwaliti na sefti standet bilong wol.
Samting
80cc Hai Pefomens Haidrolik Mota
Wantaim 15000 lb Kapasiti, Gutpela Long Ol Trela, Rol Bek Kari, Na Ol Bikpela Diuti Aplikesen.
Spring Applied Disc Brake Designed
Long holim ful reit lod.
Tupela Stet Planet Gia
Ol i wokim spesel seip bilong mekim isi long putim na luk nais.
Wok
Long Tow Truck, ngineering vehicle, trak, tractors, rollback, skid steer, bobcat, jeep, excavator, atv, utv, suv.
★ 15000 lb 'hydraulic winch' em i no bilong apim.
OL SPESIFIKESEN
| Pulim lain | 15000 lbs (6803 kgs) |
| Motor: magnet i stap oltaim | 80ml/r |
| Oil ron | 5-40L/min |
| Presa | 14MPa |
| Brek | Otometik breking |
| Geartrain | 2-stet planet gia |
| Gia ridaksen resio | 27:1 |
| Klats | menuel |
| Kebol (Dia×L) | Ø10mm×24m |
| Sais bilong dram (Dia×L) | Ø3.5"×8. 6" (Ø89mm×220mm) |
| Bolt paten bilong putim | 10 "×4.5 " (254mm×114.3mm) 4-M12 |
| Net weit | 98lbs(44KG) |
Ol sais bilong instolesen
OL SPEKS BILONG PEFOMENS (namba wan leit)
| Pulim lain lbs(kgs) |
Ron G/min(L/min) |
Spit bilong lain ft/min(m/min) |
| 0 | 1.3(5.0) | 1.64(0.5) |
| 4000(1814) | 2.6(10.0) | 3.6(1.1) |
| 8000(3628) | 5.3(20.0) | 7.2(2.2) |
| 12000(5443) | 9.2(35.0) | 12.4(3.8) |
| 15000(6803) | 10.6(40.0) | 16.4(5.0) |
Line Pull and Rope Capacity Inlayer (HWN15000)
| Leit bilong waia rop | Pulim lain lbs(kgs) |
Rop olgeta long dram ft (m) |
| 1 | 15000(6803) | 16.4 (5.0) |
| 2 | 13454(6103) | 37.2(11.3) |
| 3 | 11210(5085) | 60.9(18.6) |
| 4 | 9596(4353) | 83.7(25.5) |
